SunnySky X2814 900KV SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: Other

Unit Type: piece

Tool Supplies: Assembled class

Technical parameters: Value 4

Remote Control Peripherals/Devices: Motor

Recommend Age: 18+,12+y

RC Parts & Accs: Motors

Package Weight: 0.15kg (0.33lb.)

Package Size: 9cm x 6cm x 5cm (3.54in x 2.36in x 1.97in)

Origin: Mainland China

Model Number: X2814 920KV

Material: Metal

Four-wheel Drive Attributes: Motors

For Vehicle Type: Airplanes

Brand Name: uuustore

SunnySky 2814 X2814 900KV 3-5S Brushless Motor for Believer UAV 1960mm RC Airplane Helicopter Fixed-wing Drone RC Motor

X2820 920KV 3-5S Brushless Motor
Specifications:
Model: X2820
KV (rpm/min): 920KV
Stator diameter: 28mm
Stator thickness: 20mm
No. of stator arms: 12
No. of rotor poles: 14
No-load current: 1.1A
Motor resistance: 28m
Max continuous current: 52A/30S
Max continuous power: 750W
Rotor diameter: 35mm
Shaft diameter: 5mm
Body length: 42mm
Overall shaft length: 61mm
Max Lipo cell: 3-5S
Recommended ESC: 60A
Recommended propeller: APC13*6.5, APC12*8, APC12*6, APC11*5.5, APC11*8, APC11*7
Motor weight: About 146g/pcs

Package list:

2* Motor
