STMICROELECTRONICS Expansion Board, STSPIN230 Low Voltage 3-Phase Brushless DC Motor Driver

X-NUCLEO-IHM11M1 Low Voltage 3-Phase Brushless DC Motor Driver

An affordable solution for portable motor-driving applications

• Voltage Range: 1.8 V to 10 V
• Current: Up to 1.3 A
• Control: Current control with adjustable off-time
• Protection: Full protection overcurrent and short circuit
• Compatibility: Arduino UNO R3 connector, STM32 Nucleo boards
• Connectors: ST morpho connectors, Hall/Encoder motor sensor connector
• Regulation: Potentiometer available for speed regulation

Top Features:

• Low voltage range for versatile applications
• Current control with adjustable off-time
• Full protection against overcurrent and short circuits
• Compatible with Arduino UNO R3 and STM32 Nucleo boards

The X-NUCLEO-IHM11M1 is a low voltage three-phase brushless DC motor driver expansion board based on the STSPIN230 for STM32 Nucleo. It provides an affordable and easy-to-use solution for the implementation of portable motor-driving applications such as thermal printers, robotics, and toys. The board is designed for six-step and FOC algorithms.

Package Includes: 1 x STMICROELECTRONICS Expansion Board, STSPIN230 Low Voltage 3-Phase Brushless DC Motor Driver

Images are for illustration only; actual product may vary.
