Name: MAD BSC 4315 V1.0 450KV FPV Drone Motor, 12N14P, M6 Prop Nut, 6mm Shaft, 600mm Leads
SKU: ELAC22173209726
Availability: InStock

Description
Reviews (0)

Overview

The MAD BSC 4315 450KV is an FPV drone motor designed for applications using 1315 inch propellers. The BSC series is positioned as an entry-level FPV brushless motor line, balancing cost effectiveness with consistent build quality. For a more durable and more aesthetic motor in the same type, the FS series is an alternative option.

Key Features

450KV rating
12N14P motor configuration
M6 propeller nut mount
6 mm shaft (inner diameter specified as IN: 6 mm)
Long silicone leads: 600 mm, 14# AWG (Black)

Specifications

Motor model	BSC 4315 V1.0
KV (RPM/V)	450KV
Slots / poles	12N14P
Motor size	D: 51 x 59.8 mm
Rotor balance	5mg
Motor balance / mounting pattern	D:30 M4x4
Propeller mounting	M6 Nut
Additional mounting marking	12-M3x2
Shaft diameter	IN: 6 mm
Cable length	600 mm, 14# AWG (Black) silicone
No-load current	1.6 A / 10 V
Internal resistance	33m
Maximum current	75 A
Maximum power	2296 W
Maximum thrust	6.13 kg
Optimized weight	254 g
Motor weight (without wire)	254 g
Product boxed weight	300 g

Test Data (8S)

Test notes

Test motor/kv: MAD BSC4315 450KV
Input voltage for the graph notes: 32 V
Ambient conditions for the graph notes: 25C, sea level
Notes: Rotational speed was adjusted by the throttle. Maximum thrust may depend on battery level, propeller type, air pressure, and other conditions.

Prop: GF1383 (8S)

Throttle (%)	Voltage (V)	Current (A)	Input Power (W)	RPM	Thrust (gf)	Efficiency (gf/W)
30	32.6	2.70	88.0	4081	735	8.4
35	32.5	3.86	125.3	4660	1002	8.0
40	32.5	5.25	170.5	5240	1229	7.2
45	32.4	6.90	223.4	5767	1486	6.7
50	32.3	9.18	296.6	6385	1820	6.1
55	32.2	12.20	393.4	7017	2251	5.7
60	32.1	15.83	508.7	7612	2695	5.3
65	32.0	19.50	624.2	8148	3093	5.0
70	31.9	23.58	752.9	8664	3474	4.6
75	31.8	28.03	891.8	9141	3867	4.3
80	31.7	33.16	1050.5	9595	4294	4.1
85	31.5	39.14	1233.6	10007	4780	3.9
90	31.4	45.54	1428.5	10403	5235	3.7
95	31.2	52.42	1636.2	10775	5665	3.5
100	31.0	61.22	1897.1	11213	6134	3.2

MAX: 115C

Prop: HQ1393 (8S)

Throttle (%)	Voltage (V)	Current (A)	Input Power (W)	RPM	Thrust (gf)	Efficiency (gf/W)
30	32.5	3.38	109.9	3832	876	8.0
35	32.5	5.18	168.2	4498	1217	7.2
40	32.4	7.35	237.9	5025	1535	6.5
45	32.3	9.78	315.7	5549	1875	5.9
50	32.2	12.87	414.6	6069	2253	5.4
55	32.1	17.10	549.0	6611	2727	5.0
60	32.0	21.77	695.6	7125	3162	4.5
65	31.8	27.03	859.8	7579	3619	4.2
70	31.6	32.72	1035.4	7981	4074	3.9
75	31.5	38.35	1208.0	8372	4420	3.7
80	31.3	44.39	1391.2	8728	4764	3.4
85	31.2	51.13	1596.0	9037	5126	3.2
90	31.0	58.45	1813.4	9288	5492	3.0
95	30.8	65.41	2014.7	9511	5740	2.8
100	30.6	75.06	2296.7	9813	6055	2.6

MAX: 122C

Applications

1315 inch prop FPV multirotors

For compatibility questions (prop selection, 8S setup, mounting pattern, or lead length), contact support at support@ or visit https:///.

Whats Included

1x MAD BSC 4315 450KV motor (other items not specified).

Details

MAD BSC 4315 V1.0 motor mounting dimensions are provided for fitment planning, including a 51mm body diameter and M6 shaft.

The MAD BSC4315 V1.0 450KV motor is listed at 254g with up to 6.13kg thrust, with performance curves and test tables to help match props and ESC settings.
