XeRun XR8 Pro G3 ESC

Bottomline:

The product features three common profiles that are suitable for all 1/8 Racing applications, allowing users to select and use them instantly. These profiles include Zero timing-Blinky mode, 1/8 Off-Road Racing mode, and 1/8 On-Road Racing mode.
XR8 PRO G3 ESC offers 32 built-in adjustable parameters, providing flexibility to meet various power requirements. These parameters can be easily imported and exported, facilitating communication and learning among drivers.
The ESC supports firmware upgrades, which can be done using the multi-function LCD G2 programming box, OTA Programmer, or Tunalyzer (available for purchase). This allows users to enjoy the latest functions and enhancements.
With the built-in switch mode BEC, the ESC provides a maximum output of 12A and allows adjustable voltage options of 6V or 7.4V. This flexibility is ideal for usage with servos and other devices that require different voltage levels.
The ESC includes a built-in reverse connection protection circuit, ensuring the ESC is protected from damage in case of reverse connection.
The ESC features a data logging function, allowing users to view various running data through the HW LINK app using the OTA Bluetooth module. This provides valuable insights and analysis for performance evaluation.

Spec & Technical data:

The Hobbywing XeRun XR8 PRO G3 Combo includes a sensored/sensorless brushless motor with peak current ratings of 200A (continuous) and 1080A (short-term). This motor is suitable for various applications, including 1/8 off-road, on-road racing, and 1/10 short course trucks. With a KV rating of 4000 and a 3660 size, this motor can be powered by up to 4S lithium-ion batteries. The ESC features a BEC output that is adjustable between 6V and 7.4V, with continuous current handling up to 6A (switch-mode).

XeRun 3660SD G2 Motor

Bottomline

ROAR approved

Innovative 4-pole-8-magnet “staggered pole” rotor (Hobbywing-patented) with low cogging effect and torque pulsation greatly improves control feel around corners.

Built-in chip for making the motor be easily identified by HOBBYWING ESCs. When pairing it with an HWsensored ESC (i.e. XR8 SCT/Plus), the motor can work in the sensored mode at all times with great output linearity after the identification. The Turbo timing is allowed to be activated for higher output.

Magnetic ring mounted on the rotor protects the motor from signal interference and guarantees its super stability in the sensored mode.

With the mechanical timing adjustable from 20 degrees to 40 degrees, users are able to have different output power.

Turbine design implemented by the rotor accelerates the internal air circulation and reduces heat.

Rebuildable design (partially rebuild-able) and a screw-less motor case for easy routine maintenance effectively prolong the motor life and raise the motor efficiency.

CNC machined aluminum housing, high purity copper windings, advanced rotor structure, high-quality alloy steel output shaft, high-precision bearings for high durability and smoothness.

New-style U solder tabs at the bottom of the motor for easy soldering and wiring.

Xerun 3660sensored brushless motor

Motor Dimension:=36mm (1.417in) L=62(2.44in)

P/N	30401150	30401151	30401153
KV (no Load)	3200 Kv	3600 Kv	4300 Kv
POLE	4	4	4
LiPo (V)	2-3S	2-3S	2S
No Load Current (A)	3.7	4.1	4.7
Resistance	0.0065	0.0056	0.0038
Diameter (mm)	35.8	35.8	35.8
Shaft dia. (mm)	5	5	5
Shaft length (mm)	17	17	17
Weight	218g (7.69oz)	214g (7.55oz)	218g (7.69oz)
Recommended Combo.	–	–	–

IMPORTANT NOTE:
The Maximum Output Power is measured with 7.4V input voltage and ESC at ZERO timing. This parameter is neither the maximum input power nor the rating power, it is calculated by RPM x Torque / 9550. Because each factory runs a different testing platform, the above data may vary. Max Amp is the Current at MaxOutput Power It is a guide used for selecting the suitable power system (ESC, Motor, Gear ratio, etc.) If the actual input current of the power system is bigger than the peak parameter stated in the above table, this means that the power system settings/configuration is over its peak (or in other words, overloaded.) The KV is measured without any load on the motor and ESC at ZERO timing. Do NOT run the motor without load for long periods of time (1 minute), otherwise the motor may overheat.

1/8 mini competition
1/10 2WD/4WD short course truck
1/10 Truggy/ Monster Pro Race
Best match withXR8 SCT Pro ESC

Manufacturer limited warranty Information

Never leave this product unsupervised when it is powered on.
Ensure all wires and connections are well insulated before connecting the motor to related devices, as short circuit will damage your motor.
Please strictly follow the A-A, B-B and C-C wiring order when connecting an ESC to the motor. Never allow this product to come in contact with water, oil, fuel or other electroconductive liquids. If this happens, stop the use of your product immediately and let it dry carefully.
Read through the manuals of all power devices and chassis and ensure the power configuration is rational before using this unit.
Never hit full throttle before installing the pinion, as high-speed rotation may cause damage to the motor in circumstances of no load.
Ensure all devices are well connected, in order to prevent poor connection that may cause your vehicle to lose control or other unpredictable issues such as damage to the device.
Stop using the motor when its shell temperature exceeds 100/212; otherwise, the rotor may be demagnetized and cause irreversible damage to your motor.

Xerun4268 SD G3 Motor

ROAR Approved

Suitable for1/8th SCT, Buggy and Touring Car
Turbo Timing Technology
Full Sensored mode (when paired with XR8 Plus G2S ESC)
Adjustable Timing (Bi-Directional) 20-40 degrees
Advanced Hall Sensor System
4-pole-8-magnet “Staggered Pole” rotor – HOBBYWING Patented design
Guarantees users the effective heat dissipation and dust prevention
The use of double insulated windings (240C R-rated), NMB bearings from Japan, and the high-intensity adhesive (340C) guarantees users the outstanding performance and super durability.

Specification

Xerun 4268SD Motor

p/n	30401906	30401907	30401908	30401910	30401909
kv	1900kv	2200kv	2000kv	2400kv	2800kv
pole	4	4	4	4	4
Lipo	2S-6S	2S-6S	2S-6S	2S-4S	2S-4S
R. ()	0.0075	0.0069	0.0069	0.0059	0.0035
no load current (A)	4A	4.1A	4.2A	4.3A	6.1A
Size. O.Dia / Length (mm)	42/68	42/68	42/68	42/68mm	42/68
Weight (g)	315	285	285	276g	300
Vehicles	1/8OffRoad	1/8OffRoad	1/8OnRoad	1/8OnRoad	1/8 OnRoad
