Flashhobby D5065 EVO 270KV Fixed Wing Motor, 12N/14P 50×64.2mm Brushless DC Motor for 3-6S LiPo

Flashhobby D5065 EVO 270KV Fixed Wing Motor, 12N/14P 50×64.2mm Brushless DC Motor for 3-6S LiPo

Flashhobby D5065 EVO 270KV Fixed Wing Motor, 12N/14P 50×64.2mm Brushless DC Motor for 3-6S LiPo

Original price was: $129.00.Current price is: $64.50.
  • SKU:A2380048365
  • Category:
  • Free shipping on orders over $40!
  • Secure Payment: Guaranteed safe & secure checkout with encrypted protection.
  • Return within 30 days. Duties & taxes non-refundable.

Overview

The Flashhobby D5065 EVO 270KV fixed wing motor is a brushless DC outrunner motor designed with a 12N/14P configuration and a 50 x 64.2 mm motor size. It is specified for 3-6S LiPo input and includes a 90 mm motor cable.

Key Features

  • 48H level magnet
  • Precision balanced rotor test
  • 14P12N high-torque motor design
  • CNC 6061-T6 aluminum bell
  • High RPM imported (NSK/NMB) bearing
  • High temperature resistant copper wire winding

Specifications

Model D5065 EVO
KV 270KV (custom KV available)
Weight (including wires/cable) 445.4 g
Motor size 50 x 64.2 mm (50 x 64.2 mm)
Motor cable length 90 mm
Internal resistance 0.051
Configuration 12N/14P
Shaft 8 mm (shaft size: 8 x 86.7 mm)
Stator diameter 50 mm
Stator height 64.2 mm
Motor mount 30 x 30 mm (M4 x 4)
Rated voltage (LiPo) 3-6S
Idle current 1.7/24V
Peak current (60 s) 39.39 A
Max power 961 W
Max pull 3498 G
Prop mount screw specification 5-M3
Dynamic balance control standard 3 mg

Applications

  • Fixed wing aircraft power systems
  • Helicopter (as listed by the manufacturer)
  • Robotic arm
  • Cradle coffee machine, milk tea machine
  • Electric drilling machine, mowing machine

For product selection and after-sales support, contact [email protected] or visit https://rcdrone.top/.

Details

The D5065 EVO motors dimensioned layout helps confirm shaft length, can diameter, and mounting hole spacing before installation.
