VCI SPARK 2006 3450KV 3-4S 3.5 Inch FPV Brushless Motor for Racing Freestyle Cinewhoop Drones

Overview

The VCI SPARK 2006 3450KV Brushless Motor is a high-performance powerhouse designed for 3.5-inch cinematic and freestyle FPV drones. Tuned for 34S LiPo configurations, this motor offers explosive thrust, durable thermal resistance, and precision-crafted balancemaking it ideal for aggressive freestyle flying, tight-space cinewhoop shots, or agile long-range cruising.

With a max output power of 558.24W and thrust up to 999g, this motor is engineered to push the limits while maintaining smooth control and consistent response under high current loads.

Key Features

• Ultra High KV (3450KV) for unmatched throttle responsiveness

• Rated for 3S4S LiPo, optimized for cinewhoops and agile racing quads

• Massive 999g of thrust and peak current up to 34.89A

• Premium-grade N52SH arc magnets and 260C high-temp copper wire

• Lightweight design (21g including wires), with 7075 aluminum and reinforced base

• Low internal resistance (45m) for higher efficiency and cooler operation

Technical Specifications

Test Data (With GF D90-3 Propeller @ 4S)

Applications

• 3.5″ Cinewhoop Drones

• Freestyle Racing Builds

• Power-focused 4S Ultralights

Why Choose SPARK 2006 3450KV?

• Delivers insane thrust while maintaining reasonable heat levels

• Perfect match for high-speed acrobatics and cinematic dynamic shots

• Durable construction and excellent thermal resistance for long-lasting use

Spark 2006 Motor specifications: KV ratings (1850, 2150, 3450), stator, resistance, voltage, current, thrust, efficiency, power, RPM, temperature. Includes load test parameters for multiple models.
