T-motor MN4120 KV400 Brushless Motor SPECIFICATIONS

Name: T-motor MN4120 KV400 Brushless Motor Max Thrust 4.3KG for RC Helicopters Drone
SKU: WKA86610369447
Availability: InStock

Use: Vehicles & Remote Control Toys

Recommend Age: 14+y

RC Parts & Accs: Motors

Origin: Mainland China

Model Number: MN4120 KV400

Material: Metal

For Vehicle Type: Helicopters

Brand Name: T-MOTOR

Specifications:

KV…………………………………………………………………………………………………400Configu ration………………………………………………………………………..12N14PStator Diameter………………………………………………………………………..41mmStator Length……………………………………………………………………………20mmShaft Diameter……………………………………………………………………………4mmMotor Dimensions(Dia.*Len)………………………………………..49.742mmWeight (g)…………………………………………………………………………………….253gldle current(10)@10v(A)………………………………………………………………..1.2ANo.of Cells(Lipo)………………………………………………………………………….4-8SMax Continuous current(A)180S……………………………………………………47AMax Continuous Power(W)180S………………………………………………1050W

Max. efficiency current……………………………………………………(10-30A)>84%
internal resistance……………………………………………………………………..30ohm
