T-Motor A6-X Modular Propulsion System 12-14S KV180 + 80A FOC ESC + MF2311P 23in Prop for 5L/10L

Overview

The T-Motor A6-X Modular Propulsion System is a matched motor + ESC + propeller power set for 5L quadcopter or 10L hexacopter agricultural drones. Recommended configurations include 5L load capacity (liquid) for agriculture quadcopter drones and 10L load capacity (liquid) for agriculture hexacopter drones, with typical take-off weight ranges of 1420 kg (quadcopter) and 2130 kg (hexacopter).

Key Features

• Modular setup: A6-X (Motor) + 14S FOC 80A (ESC) + MF2311P (Propellers)
• Recommended battery: 1214S (LiPo)
• Rated thrust: 3.55 kg; max thrust: 12 kg
• Efficiency at rated thrust: 7.46 g/W (4.2 kg)
• Ingress protection: IPX6
• ESC control method: PWM/CAN; CAN protocols: DRONE CAN, UAV CAN, CUBE CAN

Specifications

Motor Specs

ESC Specs

Prop Specs

Analysis Chart Labels

• X-axis: Thrust (gf)
• Y-axes/series labels: Eff (%), RPM, Torque (Nm), Current (A), Efficiency (gf/W), Power (W)

Whats Included

• A6-X Modular Propulsion System 1 (Excl. Carbon Tube)
• Parts Bag 1

Applications

• Agriculture quadcopter drones (recommended 5L load capacity liquid; 1420 kg take-off weight)
• Agriculture hexacopter drones (recommended 10L load capacity liquid; 2130 kg take-off weight)

For product selection and integration support, contact [email protected] or visit https://rcdrone.top/.

Details

The T-Motor setup pairs a wide two-blade propeller with a compact motor body for a clean, balanced installation.

The 23-inch propeller design includes a detailed hub layout with labeled mounting holes and carbon tube depth measurements for accurate fitment.

Performance curves map thrust against RPM, torque, current draw, power, and efficiency to help compare operating points.

The A6-X modular propulsion system includes a folding propeller assembly and a parts bag with straps and mounting screws for installation.
