T-Hobby M0703 II 27000KV Micro Motor (10*13.6mm) for 1S 3.7V, 2g, 9N12P, 681X bearings

T-Hobby M0703 II 27000KV Micro Motor (10*13.6mm) for 1S 3.7V, 2g, 9N12P, 681X bearings

T-Hobby M0703 II 27000KV Micro Motor (10*13.6mm) for 1S 3.7V, 2g, 9N12P, 681X bearings

Original price was: $19.00.Current price is: $15.20.
  • SKU:A2380050539
  • Category:
  • Free shipping on orders over $40!
  • Secure Payment: Guaranteed safe & secure checkout with encrypted protection.
  • Return within 30 days. Duties & taxes non-refundable.

Overview

T-Hobby M0703 II 27000KV micro motor with published technical drawing, electrical specs, and thrust test data for 1S (3.7V) setups.

Key Features

  • KV rating: 27000KV
  • Configuration: 9N12P
  • Bearings: Imported 681X
  • Coil insulation test: 200V withstand voltage test (3S)
  • Magnet: Nickel plated arc magnet

Specifications

Type M0703II
Motor dimension 10*13.6mm
Shaft diameter 1mm
Prop adapter 1.4*3mm
Configuration 9N12P
Bearings Imported 681X
Magnet Nickel plated arc magnet
Waterproof and dustproof class /
Dynamic balance requirements standards >= 3mg
Coil insulation test 200V withstand voltage test (3S)
Lead 30# 32/GP-1.25mm
Packing size 90*30*20mm
Packing weight 10g

Tech Specs

Recommended voltage KV27000
Rated voltage (Lipo) 3.7V
Idle current (10V) 1.6A
Internal resistance 145mOhm
Peak current (1s) 6A
Max power (1s) 22.4W
Max thrust 31.7g
Weight (incl. cable) 2g

For order support and product questions, contact https://rcdrone.top/ or [email protected].

Recommended

Motor T-HOBBY M0703II KV27000
Prop T-HOBBY M12199-3
ESC T-HOBBY F411 AIO 1S 6A
Frame type X1/WHOOP
Lipo cells 1S
Recommended take off weight range Within 30g
Max take off weight 50g

Test Data

M12199-3 (3.7V)

Throttle (%) Current (A) RPM Thrust (g) Power (W) Efficiency (g/W)
10 0.4 11500 1.4 1.5 0.91
20 0.8 20083 4.1 2.9 1.40
30 1.3 26050 7.1 4.7 1.53
40 1.8 31450 10.3 6.5 1.57
50 2.3 35966 13.5 8.5 1.59
60 2.9 39683 16.2 10.8 1.50
70 3.6 42916 19.3 13.3 1.45
80 4.3 45666 22.6 16.0 1.41
90 5.0 49750 25.2 19.3 1.31
100 6.0 52915 28.2 22.4 1.26

GF1219S-3 (3.7V)

Throttle (%) Current (A) RPM Thrust (g) Power (W) Efficiency (g/W)
10 0.4 12016 0.8 1.5 0.52
20 0.8 21015 3.7 2.9 1.27
30 1.2 27700 6.3 4.6 1.38
40 1.7 33333 9.7 6.4 1.51
50 2.3 37803 12.6 8.4 1.51
60 2.8 41666 15.7 10.4 1.50
70 3.4 45666 18.4 12.7 1.45
80 4.2 49266 21.6 15.4 1.40
90 5.2 52633 25.1 19.1 1.32
100 5.9 55866 28.6 21.7 1.32

GF120B-3 (3.7V)

Throttle (%) Current (A) RPM Thrust (g) Power (W) Efficiency (g/W)
10 0.4 12600 1.3 1.5 0.84
20 0.8 22216 4.1 2.9 1.42
30 1.2 29933 7.3 4.5 1.61
40 1.7 35850 11.0 6.3 1.74
50 2.2 40650 14.6 8.2 1.78
60 2.7 45250 17.6 10.1 1.76
70 3.4 47850 21.0 12.6 1.71
80 4.3 53483 25.0 15.9 1.57
90 5.1 55566 28.4 18.9 1.50
100 5.7 59116 31.7 21.1 1.50

Whats Included

  • Motor*1
  • Parts Bag*1

Applications

  • 1S builds (3.7V) where a 27000KV micro motor is required
  • Recommended frame type: X1/WHOOP

Details

T-Hobby M0703 II KV27000 motor specs list a 1013.6mm size for 1S (3.7V) setups, with a packing list of one motor and a small parts bag.
