SPECIFICATIONS

Wheelbase: Upper Shell

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: Motor

Tool Supplies: Grinded

Technical parameters: Value 2

Remote Control Peripherals/Devices: Motor

Recommend Age: 14+y

RC Parts & Accs: Motors

Origin: Mainland China

Model Number: D4250

Material: Metal

Four-wheel Drive Attributes: Motors

For Vehicle Type: Airplanes

Brand Name: Skyquist

Features:

48H Level Magnet

Precision Balanced Rotor Test

14P12N High Torque Motor Design

CNC 6061-T6 Aluminum Bell

High RPM Imported(NSK/NMB) Bearing

High Temperature Resistant Copper Wire Winding

Weight: 55.7g(Including wires)

Motor Size: 28 x26mm

Shaft Size: 3.0*43.0mm

Motor Mount: 16*19mm(M3*4)

Configuration: 12N14P

KV Value: 930KV, 1000KV,1450KV,2200KV or customed KV

Working TemperatureRange:-0~+80

Control Method:Use ESC And Adjust PWM signal For Control,PWM Adjustment Range 900- 2100US

Motor Type: Outrunner Brushless Motor,Three-phase Motor

KV: 930KV

Max watts: 162.9W

Max Current: 13.2A

No Load current: 0.63A

Resistance: 156.3m

Battery: 3-4S Lipo

Suggested Prop: 9 inch prop

KV: 1000KV

Max watts: 292W

Max Current: 18.43A

No Load current: 0.7A

Resistance: 137.9m

Battery: 3-4S Lipo

Suggested Prop: 9 inch prop

KV: 1450KV

Max watts: 367W

Max Current: 30.97A

No Load current: 1.26A

Resistance: 30.5m
